Product Details:
|
| Wavelength Accuracy: | ± 0.1 Nm | Output Power: | ≥ 8.0 MW |
|---|---|---|---|
| Bandwidth@3 DB: | ＜ 0.1 Nm | Bandwidth@20 DB: | ＜ 0.5 Nm |
| Type Of Fiber: | Single Mode | Communication Interface: | USB |
| Highlight: | DFB distributed feedback laser,1573.71nm laser light source,distributed feedback laser 1563.05nm |
||
Multichannel DFB Distributed Feedback Laser
| Model # | UC8135 |
| Device Package | Butterfly |
| Optional Wavelength | 1523.34 / 1536.61 / 1549.32 / 1563.05 / 1573.71 |
| Wavelength Accuracy | ± 0.1 nm |
| Output Power | ≥ 8.0 mW |
| Connector Type | FC/APC |
| Bandwidth@3 dB | ＜ 0.1 nm |
| Bandwidth@20 dB | ＜ 0.5 nm |
|
Output Power Stability within 15mins |
≤ ±0.005 dB |
|
Output Power Stability within 8 hrs |
≤ ±0. 05 dB |
| Type of fiber | Single Mode |
| SMSR | ＞ 40 dB |
| Communication interface | USB |
| Operation Temperature | 0～+30 ℃ |
| Storage Temperature | -20～+70 ℃ |
| Dimensions | 235 mm W, 55 mm H, 320 mm D |
| Weight | 3.0 kg |
UC8135 multi-channel DFB light source can be used for WDM devices, HIGH precision WDM DWDM devices, optical waveguide grating array AWG devices, plane optical waveguide PLC devices, optical amplifier EDFA and other general optical measurement and application, especially suitable for the mass production of couplers and plane optical waveguide PLC components detection.
UC8135 multi - channel DFB light source has the characteristics of high output stability, small volume and fast start-up. Light source equipment can provide multiple channels of fixed wavelength light source output signal. Youxi Instrument can also customize light source equipment with ITU wavelength combinations such as 1523.34/1536.61/1549.32/1563.05/1573.71nm according to customer requirements.
FAQ
Q: Are you a factory manufacturer?
A: Yes we are manufacturer with 13 years experience in this industry and supplied many good quality products.
Q: Where is your main market?
A: Asia, Europe, America, Middle-East, Africa and other countries and regions.
Q:What is your minimum order quantity (MOQ)?
A: As a standard policy, we accept MOQ of 1set, and mixed items available, it still needs to confirm with our sales according to different product lines.
Q: Can I customize the size and color of the case?
A: Yes. We can discuss it .
Q: Can I buy some samples first before main orders? Is the sample fee refundable?
A: Yes, sample fee and shipment fee should be paid in advance .
Q: How long is the Production Lead Time?
A: 5 days for stock products, different products have different delivery times, according to the actual situation.
