1390nm 1410nm 1430nm Multichannel DFB Laser Source Four Channel

1390nm 1410nm 1430nm Multichannel DFB Laser Source Four Channel
1390nm 1410nm 1430nm Multichannel DFB Laser Source Four Channel

Large Image :  1390nm 1410nm 1430nm Multichannel DFB Laser Source Four Channel

Product Details:
Place of Origin: China
Brand Name: YOUCii
Certification: CU,IOS
Model Number: U8124
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: negotiate a price
Packaging Details: cartons
Delivery Time: 10 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10 pcs+ per year

1390nm 1410nm 1430nm Multichannel DFB Laser Source Four Channel

Description
Model: U8124
Highlight:

1430nm DFB Laser Source UC

,

1390nm laser driven light source

,

1410nm DFB Laser Source

U8124 Multichannel DFB Laser Source



Specification



Model U8120
Device Package TO
Optional Wavelength

850/980/1270/1290/1310/1330/1350/1370/1390/1410/1430/

1450/1470/1490/1510/1530/1550/1570/ 1590/1610/1625 nm etc.
Wavelength Accuracy ± 3 nm
Output Power ≥1.0mW
Connector Type FC/APC (Other Adaptor Can Be Customized)
Bandwidth@3 dB < 0.1 nm
Bandwidth@20 dB < 0.5 nm
Output Power Stability within 15mins ≤±0.01 dB
Output Power Stability within 8 hrs ≤±0. 05 dB
SMSR > 35 dB (850/980nm),> 40 dB(1270nm etc.)
Operation Temperature 0~ +40 ℃
Storage Temperature -30~+80 ℃
Dimensions 235 mm W, 55 mm H, 320 mm D
Weight 3.0 kg

Note: Single Channel model Single Channel: U8131, Double Channel model Double Channel: U8132, Four Channel model Four Channel: U8134, etc.



   U8120 Multichannel DFB laser source offer superior performance for the testing of CWDM, DWDM components, AWG & PLC components, optical amplifiers, and other general purpose fiber optic test and measurement applications. It is specifically designed for high volume CWDM, couplers and PLC production line application.

   U8120 Multichannel DFB laser source is a high stability, compact-sized, fast-starting, and affordable optical laser source. It provides Multichannel high performance, fixed wavelength output. Any two or four and more of the following channels can be provided on request: 850, 980, 1250, 1270, 1290, 1310, 1330, 1350, 1370, 1390, 1410, 1430, 1450, 1470, 1490, 1510, 1530, 1550, 1570, 1590, 1610, or 1625 nm and etc.
