Double Channel Model DFB Laser Source 1290nm 1310nm 1330nm

Double Channel Model DFB Laser Source 1290nm 1310nm 1330nm
Double Channel Model DFB Laser Source 1290nm 1310nm 1330nm

Large Image :  Double Channel Model DFB Laser Source 1290nm 1310nm 1330nm

Product Details:
Place of Origin: CHINA
Brand Name: YOUCii
Certification: CU,IOS
Model Number: U8122
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: negotiate a price
Packaging Details: Carton
Delivery Time: 20 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 15pcs+per month

Double Channel Model DFB Laser Source 1290nm 1310nm 1330nm

Description
Highlight:

UC DFB Laser Source 1310nm

,

1330nm laser lab source

,

DFB Laser Source 1290nm

U8122 DFB Laser source



Specification



Model U8122
Device Package TO
Optional Wavelength 850/980/1270/1290/1310/1330/1350/1370/1390/1410/1430/
Wavelength Accuracy ± 3 nm
Output Power ≥1.0mW
Connector Type FC/APC (Other Adaptor Can Be Customized)
Bandwidth@3 dB < 0.1 nm
Bandwidth@20 dB < 0.5 nm
Output Power Stability within 15mins ≤±0.01 dB
Output Power Stability within 8 hrs ≤±0. 05 dB
SMSR > 35 dB (850/980nm),> 40 dB(1270nm etc.)
Operation Temperature 0~ +40 ℃
Storage Temperature -30~+80 ℃
Dimensions 235 mm W, 55 mm H, 320 mm D
Weight 3.0 kg

Note: Single Channel model Single Channel: U8131, Double Channel model Double Channel: U8132, Four Channel model Four Channel: U8134, etc.



U8120 Multichannel DFB laser source offer superior performance for the testing of CWDM, DWDM components, AWG & PLC components, optical amplifiers, and other general purpose fiber optic test and measurement applications. It is specifically designed for high volume CWDM, couplers and PLC production line application.

U8120 Multichannel DFB laser source is a high stability, compact-sized, fast-starting, and affordable optical laser source. It provides Multichannel high performance, fixed wavelength output. Any two or four and more of the following channels can be provided on request: 850, 980, 1250, 1270, 1290, 1310, 1330, 1350, 1370, 1390, 1410, 1430, 1450, 1470, 1490, 1510, 1530, 1550, 1570, 1590, 1610, or 1625 nm and etc.



FAQ
Q: Are you a factory manufacturer?
A: Yes we are manufacturer with 13 years experience in this industry and supplied many good quality products.
Q: Where is your main market?
A: Asia, Europe, America, Middle-East, Africa and other countries and regions.
Q:What is your minimum order quantity (MOQ)?
A: As a standard policy, we accept MOQ of 1set, and mixed items available, it still needs to confirm with our sales according to different product lines.
Q: Can I customize the size and color of the case?
A: Yes. We can discuss it .
Q: Can I buy some samples first before main orders? Is the sample fee refundable?
A: Yes, sample fee and shipment fee should be paid in advance .
Q: How long is the Production Lead Time?
A: 5 days for stock products, different products have different delivery times, according to the actual situation.
