10G Full-rate Bit Error Rate Meter With 12 Electrical Port Channels

10G Full-rate Bit Error Rate Meter With 12 Electrical Port Channels
10G Full-rate Bit Error Rate Meter With 12 Electrical Port Channels

Large Image :  10G Full-rate Bit Error Rate Meter With 12 Electrical Port Channels

Product Details:
Place of Origin: CHINA
Brand Name: YOUCii
Model Number: U9210E
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiate a price
Packaging Details: cartons
Delivery Time: 21 work days
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 5pcs+per month
Contact Now

10G Full-rate Bit Error Rate Meter With 12 Electrical Port Channels

Description
Model: U9210E Data Rate: 622M Up To 15Gbps
Material: Metal Data Output Jitter (RMS): 1.5 (10.3125G Down)ps
Place Of Origin: China Rise And Fall Time (20% To 80%): 18~23ps
Highlight:

Full-rate Bit Error Rate Meter

,

12 Port Channels Error Rate Meter

10G Full-rate Bit Error Rate Meter With 12 Electrical Port Channels


The 10G 12-channel full-rate bit error rate tester is a high-performance bit error rate testing device that supports 12 independent channels and has a rate coverage of 622M to 15Gbps (some models support custom expansion to higher rates).


Core function
Multi-channel independent testing
Wide rate range and custom rates
Support for multiple code types
The optical/electrical interface can be flexibly configured



No.

parameter

minimum

typical

maximum

unit
1

Data rate

 0.622 0.622,1.25,2.125,2.488,2.5,3.07,3.125,4.25,5.0,6.144,6.25,7.5,8.5 ,9.953,10.00,10.3125,10.52,10.709,11.09,11.32,11.7,14.025,15 15 Gbps
2

Code type
PRBS7,PRBS9,PRBS15,PRBS23,PRBS31

3

Rise and fall time (20% to 80%)
18 23 ps
4

Pattern reversal

Supports signal reversal at the receiving end

5

Signal output amplitude (single-ended)

 200 800 1000 mV
6

Data output jitter (RMS)

1.5 (10.3125G down)
ps
7

Data input/output interface

Differential, AC coupling, 50 ohm impedance, SMA

8

Clock output

 100 156.25 156.25 MHz
9

Data signal input sensitivity (single-ended)
0.1
Vpp
10

Data output eye graph intersections

 50 52 54 %
11

Operating temperature

 10 25 50 °C


Typical application scenarios
Research and development and production of optical modules
High-speed cable (DAC/AOC) testing
Data center interconnection verification
Satellite communication and aerospace
