12 Channel MWDM Light Source Tunable Laser Source High Stability Quick Start

12 Channel MWDM Light Source Tunable Laser Source High Stability Quick Start
12 Channel MWDM Light Source Tunable Laser Source High Stability Quick Start 12 Channel MWDM Light Source Tunable Laser Source High Stability Quick Start

Large Image :  12 Channel MWDM Light Source Tunable Laser Source High Stability Quick Start

Product Details:
Place of Origin: China
Brand Name: YOUCii
Certification: CU,IOS
Model Number: U8160-12
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: negotiate a price
Packaging Details: cartons
Delivery Time: 20 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10pcs+per month

12 Channel MWDM Light Source Tunable Laser Source High Stability Quick Start

Description
Device Package: Butterfly 12 Wavelength: 1267.5/1274.5/1287.5/1294.5/1307.5/1314.5/ 1327.5/1334.5/1347.5/1354.5/1367.5/1374.5
Wavelength Accuracy: ± 0.3 Nm Output Power: ≥ 10.0 MW
Connector Type: FC/APC ( Other Adaptor Can Be Customized) Bandwidth@3 DB: < 0.1 Nm
Bandwidth@20 DB: < 0.5 Nm SMSR: > 40 DB
Highlight:

12 Channel Tunable Laser Source

,

12 Channel MWDM Light Source UC

,

Tunable Laser Source High Stability

U8160-12 12 Channel MWDM Light Source High Stability Quick Start Can Be Customized



Specification



 Unit Type U8160-12
Device Package Butterfly
12 Wavelength

1267.5/1274.5/1287.5/1294.5/1307.5/1314.5/

1327.5/1334.5/1347.5/1354.5/1367.5/1374.5

Wavelength Accuracy ± 0.3 nm
Output Power ≥ 10.0 mW
Connector Type FC/APC ( Other Adaptor Can Be Customized)
Bandwidth@3 dB < 0.1 nm
Bandwidth@20 dB < 0.5 nm

Output Power Stability within 15mins

±0.005 dB

Output Power Stability within 8 hrs

±0. 05 dB
SMSR > 40 dB
Operation Temperature 0 ~ +40 ℃
Storage Temperature -30 ~ +80 ℃
Dimensions 483 mm W, 45 mm H, 320 mm D
Weight 3.0 kg



   UC8160-12 The 12-channel MWDM light source is used for the measurement application of wavelength division multiplexing MWDM devices, mainly for mass production detection of MWDM devices.



   UC8160-12 The 12- channel MWDM light source has the characteristics of high output stability, small volume and quick start. Light source equipment provides 12 channels of fixed wavelength light source output signal. Guangzhou UC can also customize the light source equipment with four wavelengths according to customer requirements. The model is defined as UC8164.

FAQ
Q: Are you a factory manufacturer?
A: Yes we are manufacturer with 13 years experience in this industry and supplied many good quality products.
Q: Where is your main market?
A: Asia, Europe, America, Middle-East, Africa and other countries and regions.
Q:What is your minimum order quantity (MOQ)?
A: As a standard policy, we accept MOQ of 1set, and mixed items available, it still needs to confirm with our sales according to different product lines.
