Product Details:
|
Operation Wavelength: | 1260 ~1360, 1460~1530, 1565~1625 Nm | Single Band Wide @-10 DB: | ≥60 Nm |
---|---|---|---|
Output Power: | ≥9dBm | Spectral Density: | ≥-26dBm/nm |
Connector Type: | FC/APC (other Adaptor Can Be Customized) | Operation Model: | CW |
Fiber Type: | Single Mode SFM-28 | Power Supply: | AC 110 ~ 220 V±10%, 50Hz/60Hz, 20W |
Highlight: | OSL band fluorescence light source,fluorescence light source 60 nm,1625 nm Tunable Laser Source |
U8143-OSL OSL band Light Source Super radiation fluorescence light source
Model # | U8143-OSL |
Operation Wavelength |
1260 ~1360, 1460~1530, 1565~1625 nm |
Single Band wide @-10 dB | ≥60 nm |
Output Power | ≥9dBm |
Spectral Density | ≥-26dBm/nm |
Connector Type | FC/APC (other adaptor can be customized) |
Spectral Density Stability within 15mins |
<± 0.03 dBm/nm |
Output Power Stability within 15mins |
<±0.01 dB |
Output Power Stability within 8 hrs |
≤± 0.05 dB |
Operation Model | CW |
Fiber Type | Single Mode SFM-28 |
Operation Temperature | 0 ~ +40℃ |
Storage Temperature | -30 ~ +80℃ |
Power Supply | AC 110 ~ 220 V±10%, 50Hz/60Hz, 20W |
Dimensions | 235mm W, 55 mm H, 320 D mm |
Weight | 3.0 kg |
UC8143-OSL broadband light source is composed of ultra-strong light-emitting diode (SLED) technology and butterfly packaging device. The single-band or full-band continuous output light source is constructed by high stability driving and controlling circuit. The single band bandwidth can reach 100nm, and the full band bandwidth can reach 400nm.
UC8143-OSL broadband light source has the advantages of high stability, small size, fast start and affordable price. It provides the output of the broadband light source in the wavelength range of 1260 ~ 1650 nm.
FAQ
Q: Are your company a trading one or a factory?
A: We are a fcatory in Guangdong. Our company has a professional foreign trade sales team and an experienced technical support team. We are supplier for Light source, optical power meter, optical attenuator, optical switch and BERT, DCA, CDR.
Q: What is the price term?
A: FOB ShenZhen
Q: What’s the warranty time?
A: 12 months after shipment date.
Q: How to place order?
A: Talk to service staff, confirm machine details, and then place order.
