MPO MTP Multi Fiber Cable Optical Return Loss Meter Insertion Loss Test System

I'm Online Chat Now

MPO MTP Multi Fiber Cable Optical Return Loss Meter Insertion Loss Test System

MPO MTP Multi Fiber Cable Optical Return Loss Meter Insertion Loss Test System
MPO MTP Multi Fiber Cable Optical Return Loss Meter Insertion Loss Test System

Large Image :  MPO MTP Multi Fiber Cable Optical Return Loss Meter Insertion Loss Test System

Product Details:
Place of Origin: CHINA
Brand Name: YOUCii
Certification: CU,IOS
Model Number: U8550
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: negotiate a price
Packaging Details: Carton
Delivery Time: 20 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 7 pcs+per month

MPO MTP Multi Fiber Cable Optical Return Loss Meter Insertion Loss Test System

Description
Product Name: Fiber Cable Optical Return Loss Meter Operation Wavelength Range: 850~1700 Nm
Power Range: 0 ~ -20 DBm Degree Of Linearity: ±0.05dB(SM),±0.1dB(MM)
Application Fiber Type: Standard Singlemode Or Multimode Fiber Insertion Loss Part: Multimode MM
Highlight:

MTP Optical Return Loss Meter

,

Multi Fiber Cable insertion loss meter

,

MPO Optical Return Loss Meter

U8550 MPO/MTP Multi-fiber cable insertion loss test system



Model # U8550-08 U8550-12 U8550-24
Number of Channels 8 12 24
Sensor Element integrating sphere
Operation Wavelength Range 850~1700 nm
Power Range 0 ~ -20 dBm
Degree of Linearity ±0.05dB(SM),±0.1dB(MM)
Application Fiber Type Standard singlemode or multimode fiber
Uncertainty 3%
Insertion Loss Part multimode MM
Center Wavelength 850 / 908 nm
Spectrum Range ± 30 nm
Type of  Light Source LED,LD optional
Fiber Core Diameter 50/125 um
Circular Flux Standard suit for IEC-61280-4-1
Output Stability ± 0.05dB(15min),±0.1dB(1hour)
Optical Interface Type FC/APC
Return Loss Part multimode MM
Type of Light Source Pulsed FP Laser
Measuring Range 14~50 dB
Measurement Accuracy ±1dB(14~40dB),±4dB(40~50dB)
Minimum Test Length 2M (terminal APC),3M(terminal PC)
Maximum Test Length 200 Meters
Communication Interface USB
Power Source 90~240V AC
Operation Temperature 0 ~ +40℃
Storage Temperature -30 ~ +80℃
Recalibration Period 2 years
Dimensions 360mm W×160mm H×345mm D
Weight 6.5 kg





U8550 MPO/MTP multi-core cable insertion loss test system is a multi-core device test equipment. Truly realize the multi-core winding free return loss test, and no end matching. Automatic 8 core, 12 core, 24 core dual-wavelength plug loss and loss test.

Sampling OTDR winding free technology greatly improves the testing accuracy and efficiency of plug back loss of multi-core devices.



FAQ
Q: Are your company a trading one or a factory?
A: We are a fcatory in Guangdong. Our company has a professional foreign trade sales team and an experienced technical support team. We are supplier for Light source, optical power meter, optical attenuator, optical switch and BERT, DCA, CDR.
Q: What is the price term?
A: FOB ShenZhen
Q: What’s the warranty time?
A: 12 months after shipment date.
Q: How to place order?
A: Talk to service staff, confirm machine details, and then place order.
