Product Details:
Place of Origin: CHINA
Brand Name: YOUCii
Certification: CU,IOS
Model Number: UFSW1×4-SM-C
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: negotiate a price
Packaging Details: Carton
Delivery Time: 20 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 20 pcs+per month

Optical Fiber Network Switch 1260nm 1650nm Working Wavelength

Description
Product Name: Optical Fiber Network Switch Working Wavelength: 1260nm 1650nm
Fiber Type: Single Mode Switching Time: ≤12ms
Storage Temperature: -40 ~ +70℃ Working Temperature: -20~ +60℃
Highlight:

fiber network switch 1260nm

,

optical level switch 1650nm

,

fiber network switch 1650nm

UFSW1×4-SM-C Optical switch



USES:

Multi-channel optical monitoring in optical transmission system;

A multi-source/detector automatic connection switching and multi-point dynamic monitoring system of optical sensing;

The system is used to test optical fibers, optical devices, networks and optical cables in field projects.

Load and adjust optical devices.



Specification

Working wavelength 1260~1650nm
Fiber Type Single Mode
Optical interface FC/PC
Insertion loss ≤1dB
Return loss ≥45dB
Crosstalk ≤-70dB
Switching time ≤12ms (sequential switching of adjacent channels)
Repeatability ≤±0.02dB
Life 3×107 times
Working temperature -20~ +60℃
Storage temperature -40 ~ +70℃
Power requirements AC 220V
Control interface RS-232
Chassis size 288mm×260mm×117mm
