Super Radiation Fluorescence Light Source 1260 ~1360 1460~1530 1565~1625Nm

Large Image : Super Radiation Fluorescence Light Source 1260 ~1360 1460~1530 1565~1625Nm

Product Details:

Place of Origin:	CHINA
Brand Name:	YOUCii
Model Number:	U8143-OSL

Payment & Shipping Terms:

Minimum Order Quantity:	1pcs
Price:	negotiate a price
Packaging Details:	Carton
Delivery Time:	20 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	5pcs+per month

Contact Now

Super Radiation Fluorescence Light Source 1260 ~1360 1460~1530 1565~1625Nm

Description

Operation Wavelength:	1260 ~1360, 1460~1530, 1565~1625 Nm	Single Band Wide @-10 DB:	≥60 Nm
Output Power:	≥9dBm	Spectral Density:	≥-26dBm/nm
Fiber Type:	Single Mode SFM-28	Power Supply:	AC 110 ~ 220 V±10%, 50Hz/60Hz, 20W
Highlight:	Super Radiation Fluorescence Light Source , 1625Nm Super Radiation Fluorescence Light Source

U8143-OSL OSL band Light Source Super radiation fluorescence light source

The light source adopts high precision automatic power control (APC) and automatic temperature control (ATC) technology, has high short-term stability and long-term stability, continuous light working mode.

Super Intensity light emitting Diode (SLED) is a new type of light emitting diode with special technology to greatly improve the output power, and its biggest advantage is large output power. According to the working wavelength, it can be divided into 1300nm SLED, 1480nm SLED, 1550nm SLED, 1620nm SLED and so on.

Super Radiation Fluorescence Light Source 1260 ~1360 1460~1530 1565~1625Nm 0

Specification

Model #	U8143-OSL
Operation Wavelength	1260 ~1360, 1460~1530, 1565~1625 nm
Single Band wide @-10 dB	≥60 nm
Output Power	≥9dBm
Spectral Density	≥-26dBm/nm
Connector Type	FC/APC (other adaptor can be customized)
Spectral Density Stability within 15mins	＜± 0.03 dBm/nm
Output Power Stability within 15mins	＜±0.01 dB
Output Power Stability within 8 hrs	≤± 0.05 dB
Operation Model	CW
Fiber Type	Single Mode SFM-28
Operation Temperature	0 ～ +40℃
Storage Temperature	-30 ～ +80℃
Power Supply	AC 110 ~ 220 V±10%, 50Hz/60Hz, 20W
Dimensions	235mm W, 55 mm H, 320 D mm
Weight	3.0 kg

Remark:Single Band Type:U8141,SUh as: U8141-C / L,Double Band Type:U8142,SUh as: U8142-CL

Three Band Type:U8143 SUh as: U8143-OSL, Full Band Type: U8144.

All spectrum and power stability tests were carried out in continuous optical output operation mode at ambient temperature of 25℃ (+/-2℃ deviation) and after the module was energized and preheated for 30 minutes.
