Product Details:
|
| Device Package: | Butterfly | Wavelength Accuracy: | ± 2 Nm |
|---|---|---|---|
| Output Power: | ≥10.0mW | Operation Temperature: | 0～ +40 ℃ |
| Storage Temperature: | -30～+80 ℃ | Optional Wavelength: | 405/1604nm |
| Highlight: | DFB Laser Source Multichannel,1604nm DFB Laser Source |
||
Distributed Feedback Laser Multichannel DFB Lasers Source 405/1604nm
The U8130 multi-channel DFB light source can be used for wavelength-division multiplexing CWDM devices and high-precision wavelength-division multiplexing DWDM devices. It has the characteristics of high output stability, small size, fast startup, etc. Besides, different wavelengths can also be customized according to customers' requirements. For example, a single-channel wavelength model would be U8131, a two-channel wavelength would be U8132, a four-channel wavelength would be U8134, and so on.
U8130 Multichannel DFB Laser Source
| Model # | U8130 |
| Device Package | Butterfly |
| Optional Wavelength | 1305/1308 |
| Wavelength Accuracy | ± 2 nm |
| Output Power | ≥10.0mW |
| Connector Type | FC/APC (Other Adaptor Can Be Customized) |
| Bandwidth@3 dB | ＜ 0.1 nm |
| Bandwidth@20 dB | ＜ 0.5 nm |
|
Output Power Stability within 15mins |
≤±0.005 dB |
|
Output Power Stability within 8 hrs |
≤±0. 05 dB |
| SMSR | ＞ 45 dB(1270nm etc.) |
| Operation Temperature | 0～ +40 ℃ |
| Storage Temperature | -30～+80 ℃ |
| Dimensions | 235 mm W, 55 mm H, 320 mm D |
| Weight | 3.0 kg |
Other users asked the following questions
What is DFB light source?
DFB laser sources are with high output power and high power and wavelength stability. The wavelengths available include the ITU grids in C and L band. Special wavelengths such as 1030 nm, 1064 nm and 1650 nm are also available.
Where are DFB lasers used?
integrated DFB lasers are widely sought in optical communication applications such as DWDM optical fiber multiplexing technology, in which a tunable laser signal is needed.
What was the light source?
A light source is anything that makes light, whether natural and artificial. Natural light sources include the Sun and stars. Artificial light sources include lamp posts and televisions.
