Product Details:
|
| Device Package: | Butterfly | Wavelength Accuracy: | ± 0.3 Nm |
|---|---|---|---|
| Output Power: | ≥ 10.0 MW | Output Power Stability Within 15mins: | ±0.005 DB |
| Output Power Stability Within 8 Hrs: | ±0. 05 DB | Operation Temperature: | 0 ～ +40 ℃ |
| Highlight: | Measurement MWDM Light Source,WDM Devices MWDM Light Source |
||
12 Channel MWDM Light Source Used For Measurement Of WDM MWDM Devices
The U8160-12 12-channel MWDM light source has the characteristics of high output stability, small size and fast start-up.
The function of U8160-12 MWDM light source is mainly reflected in the following aspects:
Firstly, it is specially designed for the measurement applications of wavelength division multiplexing (MWDM) devices, and can be widely used in mass production detection of MWDM devices. This makes quality inspection on the production line more efficient and accurate.
Second, this light source device provides 12 channels of fixed-wavelength light source output signals. This design not only meets a variety of measurement needs, but also improves the flexibility and accuracy of measurement.
Specification
| Unit Type | U8160-12 (U8164 4CH*3) |
| Device Package | Butterfly |
| 12 Wavelength |
1267.5/1274.5/1287.5/1294.5/1307.5/1314.5/ 1327.5/1334.5/1347.5/1354.5/1367.5/1374.5 |
| Wavelength Accuracy | ± 0.3 nm |
| Output Power | ≥ 10.0 mW |
| Connector Type | FC/APC ( Other Adaptor Can Be Customized) |
| Bandwidth@3 dB | ＜ 0.1 nm |
| Bandwidth@20 dB | ＜ 0.5 nm |
| Output Power Stability within 15mins | ±0.005 dB |
| Output Power Stability within 8 hrs | ±0. 05 dB |
| SMSR | ＞ 40 dB |
| Operation Temperature | 0 ～ +40 ℃ |
| Storage Temperature | -30 ～ +80 ℃ |
| Dimensions | 483 mm W, 45 mm H, 320 mm D |
| Weight | 3.0 kg |
