Double Channel Light Source Power Meter Mini 850nm 980nm

I'm Online Chat Now

Double Channel Light Source Power Meter Mini 850nm 980nm

Double Channel Light Source Power Meter Mini 850nm 980nm
Double Channel Light Source Power Meter Mini 850nm 980nm

Large Image :  Double Channel Light Source Power Meter Mini 850nm 980nm

Product Details:
Place of Origin: CHINA
Brand Name: YOUCii
Model Number: U8202M
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: negotiate a price
Packaging Details: Carton
Delivery Time: 21 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 20pcs+per month

Double Channel Light Source Power Meter Mini 850nm 980nm

Description
Color: Silver Number Of Channels: 2
Power Range: +5 ~ -70dBm Wavelength Range: 850 ~ 1700 Nm
Power Sampling Period(rate): 100 Us(10KHz) Calibration Wavelength: 850/980/1310/1490/1550/1610 Nm
Application Fiber Type: Standard SM And MM Up To 62.5 Um Core Size Uncertainty (accuracy) At Reference Condition: ± 4% (1200 Nm ~ 1610 Nm)
Highlight:

light source power meter 850nm

,

light source power meter 980nm

,

mini optical power meter 980nm

U8202M Double Channel Power Meter Module Mini Qptical Power Meter +25 ~ -50dBm



Model # U8202M U8202MH
Number of Channels 2 2
Power Range +5~ -70dBm +25 ~ -50dBm
Wavelength Range 850 ~ 1700 nm

Power sampling period(rate)

100 us(10KHz)
Calibration Wavelength 850/980/1310/1490/1550/1610 nm
Application Fiber Type Standard SM and MM up to 62.5 um core size

Absolute

Uncertainty (accuracy) at reference condition

± 4% (1200 nm ~ 1610 nm)

Relative

Uncertainty (accuracy) at reference condition

< 0.02 dB Typical
Linearity (power) ≤ ± 0.06 dB (1200 nm ~ 1610 nm, 0~ -50dBm)
Return Loss > 40 dB
Communication Interface RS232
Sampling Data Storage Support online continuous 2-hour data collection and saving, and draw power curves
Power Supply DC5V3A,100~240V AC Power adapter
Operation Temperature 0 ~ +40℃
Storage Temperature -30 ~ +80℃
Recalibration Period 2 years
Dimensions 100 mm W, 30 mm H, 165 mm D
Weight 1.0 kg





U8202M Double channel Mini optical power meters offer superior performance, economical and practical for general purpose of fiber optical test and measurement applications. It is specifically designed for use in high volume production lines.
U8202M Mini optical power meter test systems are efficient, compact sized, fast-starting, and affordable. They provide low power, high power, single channel and dual channel optical power meter options.



FAQ
Q: Are you a factory manufacturer?
A: Yes we are manufacturer with 13 years experience in this industry and supplied many good quality products.
Q: Where is your main market?
A: Asia, Europe, America, Middle-East, Africa and other countries and regions.
Q:What is your minimum order quantity (MOQ)?
A: As a standard policy, we accept MOQ of 1set, and mixed items available, it still needs to confirm with our sales according to different product lines.
Q: Can I customize the size and color of the case?
A: Yes. We can discuss it .
Q: Can I buy some samples first before main orders? Is the sample fee refundable?
A: Yes, sample fee and shipment fee should be paid in advance .
Q: How long is the Production Lead Time?
A: 5 days for stock products, different products have different delivery times, according to the actual situation.
