Portable Fast Optical Power Meter Probe Power Range + 10 ~ -55dBm 10KH

Large Image : Portable Fast Optical Power Meter Probe Power Range + 10 ~ -55dBm 10KH

Product Details:

Place of Origin:	CHINA
Brand Name:	YOUCii
Model Number:	UC88201

Payment & Shipping Terms:

Minimum Order Quantity:	1pcs
Price:	negotiate a price
Packaging Details:	Carton
Delivery Time:	20 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	15pcs+per month

Contact Now

Portable Fast Optical Power Meter Probe Power Range + 10 ~ -55dBm 10KH

Description

Sensor Element:	InGaAs	Calibration Wavelength:	980/1310/1490/1510~1640nm Continuous Calibration
Power Sampling Period(rate):	100 Us(10KHz)	Communication Interface:	USB Trig + BNC Analog Output
Linearity (power):	≤± 0.02 DB (1200 ~ 1610 Nm, + 0 ~ -50dBm)	Dimensions:	52mm H,60 Mm W,150 Mm D
Warranty:	1 Year	Weight:	1.0 Kg
Highlight:	Portable Optical Power Meter , 10KH Optical Power Meter

Portable Fast Power Meter Probe Power Range + 10 ~ -55dBm

Specification

Model#	UC88201
Sensor Element	InGaAs
Wavelength Range	900 ~ 1700 nm
Calibration wavelength	980/1310/1490/1510~1640nm Continuous calibration
Power Range	+ 10 ~ -55 dBm
Power sampling period(rate)	100 us(10KHz)
Application Fiber Type	Standard SM and MM up to 62.5 um core size
Absolute Uncertainty (accuracy) at reference condition	± 4% (1200 nm ~ 1610 nm)
Relative Uncertainty (accuracy) at reference condition	＜ 0.02 dB Typical values
Linearity (power)	≤± 0.02 dB (1200 ~ 1610 nm, + 0 ~ -50dBm)
Return Loss	＞ 40 dB
Calibration period	2 years
Optical Input Interface	Supporting bare fiber joint or FC/LC/SC Adapter
Communication Interface	USB Trig + BNC Analog output
Operation Temperature	0 ~ +40℃
Storage Temperature	-30 ~ +80℃
Dimensions	52mm H,60 mm W,150 mm D
Weight	1.0 kg

Portable Fast Optical Power Meter Probe Power Range + 10 ~ -55dBm 10KH 0
