Product Details:
|
| Calibration Wavelength: | 850/908/1270/1290/1310/1330/1510/1530/1550/1570 Nm | Application Fiber Type: | Standard SM And MM Up To 62.5 Um Core Size |
|---|---|---|---|
| Absolute Uncertainty (accuracy) At Reference Condition: | ± 4% (1200 Nm ~ 1610 Nm) | Linearity (power): | ≤ ± 0.06 DB (1200 Nm ~ 1610 Nm, 0~ -50dBm) |
| Operation Temperature: | 0 ～ +40℃ | Recalibration Period: | 2 Years |
| Highlight: | Dual Channel Optic Power Meter,Multifunctional Optic Power Meter |
||
U8204 optical power meter test systems are efficient, compact sized, fast-starting, and affordable. They provide low power, high power, single channel and dual channel optical power meter options.
Optical power meters are widely used in the installation, maintenance and troubleshooting of optical fiber communication systems. It can help engineers measure and monitor optical power levels in fiber optic links to ensure the quality and stability of optical signals. In addition, optical power meters can be used to test the performance of optical devices, such as lasers, optical amplifiers, and fiber optic transmission systems.
Youcii U8204 dual channel optical power meter is a high precision, reliable and easy to use optical network power measuring instrument. It has a wide wavelength range, high resolution up to +5~-65dB dynamic range. Its USB/RS232 data interface can easily transfer data to a PC. With its extensive range of features, the U8202 is a lightweight U8202 that is ideal for any optical networking application.
| Parameters | Description |
|---|---|
|
Number of Channels |
4 |
| Data Interface | USB/RS232 |
| Power Supply | AC Adapter |
|
Power Range |
+10 ~ -65dBm |
|
Sampling period |
100 us (10KHz) |
|
Return Loss |
＞ 40 dB |
| Dimension |
245 mm W, 105 mm H, 320 mm D |
| Weight | 2Kg |
We provide technical support and service for Optical Power Meters, so you can be sure to get the best performance from your device.
